Technisat UNIX Single LNB 40mm
High-quality satellite converter designed for use with satellite dish equipped with universal 40mm converter holder. The converter works with all DVB-S/DVB-S2 receivers. It is used for receiving satellite programs.
KEY FEATURES
Top-notch HD and UHD signal reception performance
Simple and fast installation
Ideal for installation with two TWIN decoders
ENVIRONMENT
Humidity : 10 ... 90 %
Ambient temperature : -30 ... 70 °C
NOISE FACTOR
Noise factor : 0.1 dB
OUTPUT FREQUENCY RANGE
Lower frequency range : 950 ... 1950 MHz
Upper frequency range : 1100 ... 2150 MHz
RANGE OF THE LOCAL ITY
Lower frequency range : 10.7 ... 11.7GHz
Upper frequency range : 11.7 ... 12.75 GHz
LNB CONTROL
Vertical : 10.5 ... 14 V
Horizontally : 16 ... 19 V
Band switch : 22 kHz
LOCAL OSCILLATOR
Lower frequency range : 9.75 GHz
Upper frequency range : 10.6 GHz
TECHNICAL DATA
Output : 4
Gain : 55 dB
Impedance : 75 Ω
Mounting diameter : 40 mm
Connector type : Connector F
POWER
Converter power supply : 10.5 ... 19 V
Current consumption : max. 180 mA
