Fagor LNB 201 Universal Single LNB

Fagor LNB 201 Universal Single LNB

Universal low noise block converters suitable for any offset satellite dish.

Characteristics

• Stand out for their low noise figure and high gain which together with Offset type satellite dishes make it possible to obtain merit factors ideal for collective installations
• Big Cross Polarity Rejection: 25 dB

Specifications:

• Polarity: VL, HL, VH, HH
• Input frequency (low band): 10.7 – 11.7 GHz
• Input frequency (high band): 11.7 – 12.75 GHz
• Oscillator frequency (low band): 9.75 MHz
• Oscillator frequency (high band): 10.6 MHz
• Output frequency range (low band): 950 – 1950 MHz
• Output frequency range (low band): 1100 – 2150 MHz
• Noise figure: 0.2 dB
• Cross polarity rejection: 25 dB
• Conversion gain (typical): 58 dB
• Conversion gain (max): 65 dB
• Power supply (V/H): 11.5 – 14 (V) / 16 – 19 (H) VDC
• Current consumption: < 200 mA
• Output connector: F(f)
• Operating temperature range: -25 ~ +60 °C
