Triax TSI 006 Single LNB, 7035

TRIAX TSI 006 Universal Single LNB, RAL 7035

TSI 006 Single Universal. Full KU-band coverage for both analogue and digital reception. Excellent noise figure and low phase noise. High gain and excellent cross-pole isolation. High output and low power consumption. Gain flatness.

Specifications:

Characteristics:

• Phase noise @ room temperature – 1 kHz: -50 dBc/Hz
• Phase noise @ room temperature – 10 kHz: -75 dBc/Hz
• Phase noise @ room temperature – 100 kHz: -95 dBc/Hz
• Spurious level: -60 (max) dBm
• Image rejection (min): 40 dB
• Feedhorn diameter: Ø 40 mm
• LNB type: Single
• Switching low band: 0.0 kHz
• Switching high band: 22 (± 4) kHz

Frequency

• Input frequency low band: 10.7 – 11.7 GHz
• Input frequency high band: 11.7 – 12.75 GHz
• Output frequency low band: 950 – 1950 MHz
• Output frequency high band: 1100 – 2150 Mhz
• L.O frequency low band: 9.75 Ghz
• L.O frequency high band: 10.6 Ghz

Gain

• Conversion gain (max): 62 dB
• Conversion gain (min at room temperature): 50 dB
• Conversion gain (typ.) < 62 dB
• Noise figure max: 0.3 dB

Isolation

• Cross polarization isolation: 25 typ. dB

Operational

• DC Current consumption: 100 mA
• Operating voltage vertical: 10.5 ~ 14.5 VDC
• Operating voltage horizontal: 15.5 ~ 21.0 VDC
• Operating temperature range: -40 ~ +60 °C

Connectors

• Connector type: F-female

Mechanical

• Max. depth incl. Feedhorn: 135 mm
• Product Height: 137 mm
• Product Depth: 97 mm
• Product Width: 40 mm
• Colour: RAL 7035
